WIWA HIGH PRESSURE CLEANER
- With automatic hose reel
- Constant output due to pulsation damper
- Can also be used for offshore projects thanks to ATEX certification
Description
Safe and powerful.
With our WIWA HIGH PRESSURE CLEANER you can get to grips with any dirt and prepare your surfaces in the best possible way for subsequent treatments. Pneumatically or hydraulically operated, it is used, for example, in the food industry or for building and roof renovation. Thanks to ATEX certification (pneumatic version), it is also a safe and powerful companion in potentially explosive atmospheres.
Technical Data
Model
|
60012 |
| Pressure ratio | 12:1 |
| Output per cycle | 600 ccm (20 fl.oz.) |
| Max. output (at 60 cycles/min): | 36 l/min (9.5 gallon/min) |
| Max. inbound air pressure | 7 bar (102 psi) |
| Max. operating pressure | 84 bar (1,218 psi) |
| Order number | |
| pneumatic RS/F/ASL | 0665428 |
|
Model
|
230027 |
| Pressure ratio | 27:1 |
| Output per cycle | 360 ccm (12 fl.oz.) |
| Max. output (at 60 cycles/min): | 21.6 l/min (5.7 gallon/min) |
| Max. inbound air pressure | 8 bar (116 psi) |
| Max. operating pressure | 216 bar (3,133 psi) |
| Order number | |
| pneumatic RS/F/ASL | 0665429 |
|
Model
|
270049 |
| Pressure ratio | 49:1 |
| Output per cycle | 275 ccm (9.2 fl.oz.) |
| Max. output (at 60 cycles/min): | 16.5 l/min (4.4 gallon/min) |
| Max. inbound air pressure | 5 bar (73 psi) |
| Max. operating pressure | 245 bar (3,553 psi) |
| Order number | |
| pneumatic RS/F/ASL | 0665447 |
|
Model
|
333037 |
| Pressure ratio | 37:1 |
| Output per cycle | 550 ccm (18.3 fl.oz.) |
| Max. output (at 60 cycles/min): | 33 l/min (8.7 gallon/min) |
| Max. inbound air pressure | 6.5 bar (94 psi) |
| Max. operating pressure | 240.5 bar (3,488 psi) |
| Order number | |
| pneumatic RS/F/ASL | 0665448 |
|
Model
|
60001 |
| Pressure ratio | 1.7:1 |
| Output per cycle | 550 ccm (18.3 fl.oz.) |
| Max. output (at 60 cycles/min): | 33 l/min (8.7 gallon/min) |
| Max. operating pressure | 247 bar (3,582 psi) |
| Order number | |
| hydraulic RS/F/ASL | 0665449 |
B - On container, D - on tripod, F - on chassis, G - on rack, H - on lift truck,
GZ - On Rack with feed funnel, W - on wall mount, ASL - suction tube, DAS - Direct suction
Safe and powerful.
With our WIWA HIGH PRESSURE CLEANER you can get to grips with any dirt and prepare your surfaces in the best possible way for subsequent treatments. Pneumatically or hydraulically operated, it is used, for example, in the food industry or for building and roof renovation. Thanks to ATEX certification (pneumatic version), it is also a safe and powerful companion in potentially explosive atmospheres.
|
Model
|
60012 |
| Pressure ratio | 12:1 |
| Output per cycle | 600 ccm (20 fl.oz.) |
| Max. output (at 60 cycles/min): | 36 l/min (9.5 gallon/min) |
| Max. inbound air pressure | 7 bar (102 psi) |
| Max. operating pressure | 84 bar (1,218 psi) |
| Order number | |
| pneumatic RS/F/ASL | 0665428 |
|
Model
|
230027 |
| Pressure ratio | 27:1 |
| Output per cycle | 360 ccm (12 fl.oz.) |
| Max. output (at 60 cycles/min): | 21.6 l/min (5.7 gallon/min) |
| Max. inbound air pressure | 8 bar (116 psi) |
| Max. operating pressure | 216 bar (3,133 psi) |
| Order number | |
| pneumatic RS/F/ASL | 0665429 |
|
Model
|
270049 |
| Pressure ratio | 49:1 |
| Output per cycle | 275 ccm (9.2 fl.oz.) |
| Max. output (at 60 cycles/min): | 16.5 l/min (4.4 gallon/min) |
| Max. inbound air pressure | 5 bar (73 psi) |
| Max. operating pressure | 245 bar (3,553 psi) |
| Order number | |
| pneumatic RS/F/ASL | 0665447 |
|
Model
|
333037 |
| Pressure ratio | 37:1 |
| Output per cycle | 550 ccm (18.3 fl.oz.) |
| Max. output (at 60 cycles/min): | 33 l/min (8.7 gallon/min) |
| Max. inbound air pressure | 6.5 bar (94 psi) |
| Max. operating pressure | 240.5 bar (3,488 psi) |
| Order number | |
| pneumatic RS/F/ASL | 0665448 |
|
Model
|
60001 |
| Pressure ratio | 1.7:1 |
| Output per cycle | 550 ccm (18.3 fl.oz.) |
| Max. output (at 60 cycles/min): | 33 l/min (8.7 gallon/min) |
| Max. operating pressure | 247 bar (3,582 psi) |
| Order number | |
| hydraulic RS/F/ASL | 0665449 |
B - On container, D - on tripod, F - on chassis, G - on rack, H - on lift truck,
GZ - On Rack with feed funnel, W - on wall mount, ASL - suction tube, DAS - Direct suction
